- Filtration SystemTC+UF
- FunctionsNo drain, no noise, no power requirement
High flow, tankless configuration
Hassle-free 3-second filter replacement
Slim design with footprint only 1/2 size of A4 paper
Two-year long UF filter service time
Integrated water manifold module, high-quality assurance
Ultra-filtration water system is affordable than RO system. Compared with a RO water filter system, the ultra-filtration water system keeps salutary minerals while keeping out contaminants and particles ranging from 0.01-0.1 micron, such as bacteria, viruses, parasites and harmful heavy metal ions. The ultra-filtration water filter is equipped with a post carbon block to add rare mineral elements into water, such as selenium and strontium.
- The ultra-filtration water filter is equipped with an integrated water circuit to prevent water leakage;
- Large water flow, meet household daily demands;
- Noise-reduction design, noise level as low as 40 dB;
- Compact design, easy installation;
Specifications
| Model | AW-UF-05 | |
| Rated purified water flow | 1.5L/min | |
| Filtration stages | 2 | |
| First filter lifetime | TC/6-12 months | |
| Second filter lifetime | UF/12months | |
| Input water pressure | 0.1-0.4 MPa | |
| Inlet water quality | Municipal water | |
| Inlet water temperature | 5-38℃ | |
| Working temperature | 4-40℃ (ambient) | |
| The above data is obtained from our laboratory test results. Due to the difference in water quality and water consumption, the replacement cycle of the filter element will be different, depending on the actual use. |
||
Our manufacturing plant is made up of 4 main workshops: injection molding workshop, RO membrane rolling workshop, waterway board assembly workshop and whole unit assembly workshop. And it comes equipped with 6 intelligent injection molding lines, 3 dust-free automatic filter membrane production lines, 2 automatic filter cartridge assembling lines and 4 water filter assembling lines. At injection molding workshop, there are 57 robotic manipulators with mold monitoring system that shows the status of molds in real time. In RO rolling workshop, there are anti-UV iso-temperature warehouse to store the filters. In waterway board workshop, you will witness AIBOTE pioneering waterway board production and assembly process. In whole unit assembly workshop, standardized assembly process and inspection procedure is strictly performed.
Please rest assured every Aibote product carries with Aibote people’s most attention and efforts!
